The Celanex are a semi-crystalline thermoplastic polyester Ticona - trade name of poly (butylene terephthalate).
Poly (butylene terephthalate) (PBT) is formed by the polycondensation of terephthalic acid and 1,4 - butanediol. The chemical structure is as follows:
Celanex has the following advantages:
- High-strength
- Good creep resistance
- High heat distortion temperature, especially a glass fiber reinforced level
- High hardness, high rigidity
- Low coefficient of friction and low wear
- High dimensional stability (low coefficient of linear thermal expansion, low water absorption)
- Good electrical properties
- Good chemical resistance
- Good weather resistance
- Environmental stress cracking
- Easy to spray
- Flame-retardant level (UL94: V-0, some grades can reach 5VA)
- High crystallization rate and short molding cycle
Celanex various performance grades for customers to choose:
- Melt viscosity
Different melt viscosity (fluidity), and the molecular weight can be used for injection molding and extrusion molding
- Reinforcing materials such as glass fiber reinforced
Chopped glass fiber bundle to increase the rigidity and heat resistance; performance With a great change in the variation of the glass fiber content
- Filled, such as mineral fillers and glass beads
For low warpage of plastic parts, which is usually glass beads and glass fiberglass fitted together.
- Polymer modifiers
The use of appropriate modifiers, improved surface gloss, impact strength and toughness, and reduces the melting point of raw materials and warpage.
Type | Feature | Grade | |
Non-enhanced level | Very low melt viscosity, melt-blow | 2008 | |
Very low viscosity | 2000-2 | ||
Low viscosity | 2003-2、2500 | ||
Medium viscosity, high ductility | 2002-2 | ||
Resistance to hydrolysis, impact | 2001 | ||
Glass fiber reinforced grade | 10%Glass fiber | 2300 GV1/10 | |
20%Glass fiber | 2300 GV1/20 | ||
30%Glass fiber | 2300 GV1/30 | ||
50%Glass fiber | 2300 GV1/50 | ||
15%Glass fiber, high flow | 3200-2 | ||
30%Glass fiber, high flow | 3300-2 | ||
Glass fiber reinforced polyester alloy, high surface gloss level | 15%Glass fiber | 2302 GV1/15、2303 GV1/15 | |
20%Glass fiber | 2302 GV1/20、2303 GV1/20 | ||
30%Glass fiber | 2302 GV1/30、2303 GV1/30 | ||
Low warpage grade | Glass beads enhance the level | 2300 GV3/20、2300 GV3/30 | |
Glass / mineral reinforced grades | J600、6400-2、6500 | ||
Blend level | 4306、733LD、1600A、1700A | ||
Impact modifier | 2004-2、2205 | ||
Copolyester | 2009、2025 | ||
Wear level | Unreinforced | 2002SW1 | |
Glass fiber reinforced polyester alloy, high surface gloss | 2302SW1 GV1/20 | ||
Flame Retardant | Unreinforced | 2016、2360FL | |
Glass fiber reinforced grade | 3216、3316、3314、2360 GV1/10FL | ||
Resistant to hydrolysis level | 15%Glass fiber | 3200HR | |
15%Glass fiber, high flow | 3209HR | ||
30%玻璃纤维 | 3300HR | ||
30%Glass fibers, copolymers, higher elongation at break, low-melting | 3325HR | ||
Medical / pharmaceutical grade | Medium viscosity, high ductility | 2401MT、2403MT | |
Low viscosity | 2402MT | ||
Medium viscosity, low surface tack modified | 2404MT |
